用 Docker 快速搭建 Kafka 集群

开源Linux

一个执着于技术的公众号

版本

•JDK 14•Zookeeper•Kafka

安装 Zookeeper 和 Kafka

Kafka 依赖 Zookeeper，所以我们需要在安装 Kafka 之前先拥有 Zookeeper。准备如下的 docker-compose.yaml 文件，将文件中的主机地址 192.168.1.100 替换成你自己的环境中的主机地址即可。

version: "3"services:  zookeeper:    image: zookeeper    build:      context: ./    container_name: zookeeper    ports:      - 2181:2181    volumes:      - ./data/zookeeper/data:/data      - ./data/zookeeper/datalog:/datalog      - ./data/zookeeper/logs:/logs    restart: always  kafka_node_0:    depends_on:      - zookeeper    build:      context: ./    container_name: kafka-node-0    image: wurstmeister/kafka    environment:      KAFKA_BROKER_ID: 0      KAFKA_ZOOKEEPER_CONNECT: 192.168.1.100:2181      KAFKA_ADVERTISED_LISTENERS: PLAINTEXT://192.168.1.100:9092      KAFKA_LISTENERS: PLAINTEXT://0.0.0.0:9092      KAFKA_NUM_PARTITIONS: 3      KAFKA_DEFAULT_REPLICATION_FACTOR: 2    ports:      - 9092:9092    volumes:      - ./data/kafka/node_0:/kafka    restart: unless-stopped  kafka_node_1:    depends_on:      - kafka_node_0    build:      context: ./    container_name: kafka-node-1    image: wurstmeister/kafka    environment:      KAFKA_BROKER_ID: 1      KAFKA_ZOOKEEPER_CONNECT: 192.168.1.100:2181      KAFKA_ADVERTISED_LISTENERS: PLAINTEXT://192.168.1.100:9093      KAFKA_LISTENERS: PLAINTEXT://0.0.0.0:9093      KAFKA_NUM_PARTITIONS: 3      KAFKA_DEFAULT_REPLICATION_FACTOR: 2    ports:      - 9093:9093    volumes:      - ./data/kafka/node_1:/kafka    restart: unless-stopped  kafka_node_2:    depends_on:      - kafka_node_1    build:      context: ./    container_name: kafka-node-2    image: wurstmeister/kafka    environment:      KAFKA_BROKER_ID: 2      KAFKA_ZOOKEEPER_CONNECT: 192.168.1.100:2181      KAFKA_ADVERTISED_LISTENERS: PLAINTEXT://192.168.1.100:9094      KAFKA_LISTENERS: PLAINTEXT://0.0.0.0:9094      KAFKA_NUM_PARTITIONS: 3      KAFKA_DEFAULT_REPLICATION_FACTOR: 2    ports:      - 9094:9094    volumes:      - ./data/kafka/node_2:/kafka    restart: unless-stopped

输入 docker-compose up -d 运行脚本文件进行集群构建。等待一会儿，得到如下结果即为成功。

SpringBoot 集成 Kafka 集群

创建一个全新的 SpringBoot 工程，在 build.gradle 文件中添加下列依赖。

dependencies {    ...    ...    implementation 'org.springframework.kafka:spring-kafka:2.5.2.RELEASE'    implementation 'com.alibaba:fastjson:1.2.71'}

1.在 application.properties 进行 Kafka 相关参数配置。

spring.kafka.bootstrap-servers=192.168.1.100:9092,192.168.1.100:9093,192.168.1.100:9094spring.kafka.producer.retries=0spring.kafka.producer.batch-size=16384spring.kafka.producer.buffer-memory=33554432spring.kafka.producer.key-serializer=org.apache.kafka.common.serialization.StringSerializerspring.kafka.producer.value-serializer=org.apache.kafka.common.serialization.StringSerializerspring.kafka.consumer.auto-offset-reset=latestspring.kafka.consumer.enable-auto-commit=truespring.kafka.consumer.auto-commit-interval=100

2.创建消息体类。

public class Message {    private Long id;    private String message;    private Date sendAt;}

3.创建消息发送者

public class Sender {    @Autowired    private KafkaTemplate<String, String> kafkaTemplate;    public void send() {        Message message = new Message();        message.setId(System.currentTimeMillis());        message.setMessage(UUID.randomUUID().toString());        message.setSendAt(new Date());        log.info("message = {}", JSON.toJSONString(message));        kafkaTemplate.send("test", JSON.toJSONString(message));    }}

4.创建消息接收者

public class Receiver {    @KafkaListener(topics = {"test"}, groupId = "test")    public void listen(ConsumerRecord<?, ?> record) {        Optional<?> message = Optional.ofNullable(record.value());        if (message.isPresent()) {            log.info("receiver record = " + record);            log.info("receiver message = " + message.get());        }    }}

5.测试消息队列

public class QueueController {    @Autowired    private Sender sender;    @PostMapping("/test")    public void testQueue() {        sender.send();        sender.send();        sender.send();    }}
