Unity采用Forge Networking Remastered数据的远程传输 Basic RPC Example

In this example we are going to go over how to use the built in RPC methods inside of Forge Networking Remastered. In this example we are going to make a scene that already has a cube in it, then if anyone presses the up arrow key it will move the cube up, if anyone presses the down arrow key, it will move the cube down.

Setting up the contract option 1

In this option, we will create 2 RPC methods with no arguments. One RPC is to move the cube up and the other is to move the cube down.

NOTE: Only pick option 1 or 2 to follow

Let's begin by naming our Network Object:

Let's set the name for our Network object to MoveCube
Click the Add RPC button
Name the new RPC MoveUp
Click the Add RPC button
Name the new RPC MoveDown
Click the Save & Compile button

Extending Generated Classes

When we use the Network Contract Wizard (NCW) we are actually generating a lot of network code based on what has been input into the editor fields, this actually cuts out a lot of work that you would have to do by hand. There is one class that we want to extend from, this class name will be " MoveCubeBehavior". The naming convention for this generated class is _____Behavior where "_____" is the name we typed into the NCW. Let's now create a C# file in Unity and write our basic game logic, we will name this file " MoveCube".

Open the newly created C# file
Add using BeardedManStudios.Forge.Networking.Generated; to the using statements
Derive the class from MoveCubeBehavior
Write the rest of the logic for the cube as seen below

Code if option 1 was selected

MoveCube.cs

using UnityEngine;
using BeardedManStudios.Forge.Networking.Generated;
using BeardedManStudios.Forge.Networking;
using BeardedManStudios.Forge.Networking.Unity;
public class MoveCube : MoveCubeBehavior
{
	private void Update()
	{
		// Move the cube up in world space if the up arrow was pressed
		if (Input.GetKeyDown(KeyCode.UpArrow))
			networkObject.SendRpc(RPC_MOVE_UP, Receivers.All);

		// Move the cube down in world space if the down arrow was pressed
		else if (Input.GetKeyDown(KeyCode.DownArrow))
			networkObject.SendRpc(RPC_MOVE_DOWN, Receivers.All);
	}

	/// <summary>
	/// Used to move the cube that this script is attached to up
	/// </summary>
	/// <param name="args">null</param>
	public override void MoveUp(RpcArgs args)
	{
		// RPC calls are not made from the main thread for performance, since we
		// are interacting with Unity engine objects, we will need to make sure
		// to run the logic on the main thread
		MainThreadManager.Run(() =>
		{
			transform.position += Vector3.up;
		});
    }

    /// <summary>
	/// Used to move the cube that this script is attached to down
	/// </summary>
	/// <param name="args">null</param>
	public override void MoveDown(RpcArgs args)
	{
		// RPC calls are not made from the main thread for performance, since we
		// are interacting with Unity engine objects, we will need to make sure
		// to run the logic on the main thread
		MainThreadManager.Run(() =>
		{
			transform.position += Vector3.down;
		});
	}
}

As you can see from the code snippet above an RPC is called using the networkObject.SendRPC method. The first argument is the name of the method and the second argument is the receivers of the object which could be set to things like AllBuffered, Others, etc. The moment the RPC method is called it is sent on the network to be replicated to the other clients (including server if called from a client).

Note: _In this example, it doesn't use a buffered call and it does not actually synchronize the position, so the client should be connected before the cube is moved.
