先上效果图:
Material Design系列之BottomNavigationView详解:
Material Design官方文档关于Bottom navigation部分
BottomNavigationView简介:
BottomNavigationView实现的效果就是常见的app底部导航栏的效果。
Bottom navigation bars make it easy for users to explore and switch between top-level views in a single tap. It should be used when application has three to five top-level destinations.
使用:
build.gradle中配置:
compile 'com.android.support:design:26.0.0-alpha1'
布局xml中使用:
<android.support.design.widget.BottomNavigationView
android:id="@+id/bottomNavigation"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:layout_marginEnd="0dp"
android:layout_marginStart="0dp"
android:background="?android:attr/windowBackground"
app:menu="@menu/navigation" />
menu:navigation的布局:
<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android">
<item
android:id="@+id/navigation_home"
android:icon="@drawable/home"
android:title="@string/title_home"/>
<item
android:id="@+id/navigation_type"
android:icon="@drawable/cluster"
android:title="@string/title_system"/>
<item
android:id="@+id/navigation_my"
android:icon="@drawable/user"
android:title="@string/title_my"/>
</menu>
完整的activity代码:
package wanandroid.xuboyu.com.wanandroid.ui.activity
import android.content.Intent
import android.os.Bundle
import android.support.design.widget.BottomNavigationView
import android.support.v4.app.Fragment
import android.support.v4.app.FragmentTransaction
import android.view.Menu
import android.view.MenuItem
import kotlinx.android.synthetic.main.activity_main.*
import wanandroid.xuboyu.com.wanandroid.R
import wanandroid.xuboyu.com.wanandroid.base.BaseActivity
import wanandroid.xuboyu.com.wanandroid.common.Constant
import wanandroid.xuboyu.com.wanandroid.toast
import wanandroid.xuboyu.com.wanandroid.ui.fragment.HomeFragment
import wanandroid.xuboyu.com.wanandroid.ui.fragment.MyFragment
import wanandroid.xuboyu.com.wanandroid.ui.fragment.OtherFragment
class MainActivity : BaseActivity() {
private var lastTime: Long = 0
private var homeFragment: HomeFragment? = null
private var myFragment: MyFragment? = null
private var otherFragment: OtherFragment? = null
private var currentIndex = 0
private val fragmentManager by lazy {
supportFragmentManager
}
override fun setLayoutId(): Int = R.layout.activity_main
override fun cancelRequest() {
}
override fun initImmersionBar() {
super.initImmersionBar()
immersionBar.titleBar(R.id.toolbar).init()
}
/**
* 返回键-退出
*/
override fun onBackPressed() {
val currentTime = System.currentTimeMillis()
if (currentTime - lastTime < 2 * 1000) {
super.onBackPressed()
finish()
} else {
toast(getString(R.string.double_click_exit))
lastTime = currentTime
}
}
override fun onCreate(savedInstanceState: Bundle?) {
super.onCreate(savedInstanceState)
bottomNavigation.run {
setOnNavigationItemSelectedListener(onNavigationItemSelectedListener)
selectedItemId = R.id.navigation_home
}
toolbar.run {
title = getString(R.string.title_home)
setSupportActionBar(this)
}
}
override fun onCreateOptionsMenu(menu: Menu): Boolean {
menuInflater.inflate(R.menu.menu_search, menu)
return true
}
override fun onOptionsItemSelected(item: MenuItem): Boolean {
when (item.itemId) {
//收藏网址
R.id.menuSearch -> {
Intent(this, SearchActivity::class.java).run {
this.putExtra(Constant.SEARCH_KEY, "")
this.putExtra(Constant.IS_START_SEARCH, false)
startActivity(this)
}
}
}
return super.onOptionsItemSelected(item)
}
override fun onAttachFragment(fragment: Fragment?) {
super.onAttachFragment(fragment)
when(fragment) {
is HomeFragment -> homeFragment ?: let { homeFragment = fragment }
is OtherFragment -> otherFragment ?: let { otherFragment = fragment}
is MyFragment -> myFragment ?: let { myFragment = fragment }
}
}
/**
* 显示对应Fragment
*/
private fun setFragment(index: Int) {
fragmentManager.beginTransaction().apply {
homeFragment ?: let {
HomeFragment().let {
homeFragment = it
add(R.id.content, it)
}
}
otherFragment ?: let {
OtherFragment().let {
otherFragment = it
add(R.id.content, it)
}
}
myFragment ?: let {
MyFragment().let {
myFragment = it
add(R.id.content, it)
}
}
hideFragment(this)
when (index) {
R.id.navigation_home -> {
toolbar.title = getString(R.string.title_home)
homeFragment?.let {
this.show(it)
}
}
R.id.navigation_type -> {
toolbar.title = getString(R.string.title_system)
otherFragment?.let {
this.show(it)
}
}
R.id.navigation_my -> {
toolbar.title = getString(R.string.title_my)
myFragment?.let {
this.show(it)
}
}
}
}.commit()
}
/**
* 隐藏所有fragment
*/
private fun hideFragment(transaction: FragmentTransaction) {
homeFragment?.let {
transaction.hide(it)
}
otherFragment?.let {
transaction.hide(it)
}
myFragment?.let {
transaction.hide(it)
}
}
/**
* NavigationItemSelect监听
*/
private val onNavigationItemSelectedListener =
BottomNavigationView.OnNavigationItemSelectedListener { item ->
setFragment(item.itemId)
return@OnNavigationItemSelectedListener when (item.itemId) {
R.id.navigation_home -> {
if (currentIndex == R.id.navigation_home) {
homeFragment?.smoothScrollToPosition()
}
currentIndex = R.id.navigation_home
true
}
R.id.navigation_type -> {
currentIndex = R.id.navigation_type
true
}
R.id.navigation_my -> {
currentIndex = R.id.navigation_my
true
}
else -> {
false
}
}
}
}
其他一些使用介绍的文章以及包括超过3个tab的使用可以参考下面的文章:
