不多废话,先行上图
代码:
public class MddPmdView extends View {
private Paint mPaint = null;
private int mW = 0;
private int mH = 0;
/**
* 背景圆角半径
*/
private float mRadiu = 0;
/**
* 边框线宽度
*/
private float mStockWidth = 0;
/**
* 点半径
*/
private float mCirlRadiu = 0;
/**
* 背景颜色
*/
private int mBgColor = Color.BLACK;
/**
* 边框线颜色
*/
private int mStockColor = 0xffd88341;
/**
* 线上点的个数
*/
private int mPointCount = 0;
private long duration = 0;
private List<PointF> mPoints = new ArrayList<>();
private List<Integer> colors = new ArrayList<>();
private Disposable mDisposable;
private int mRunIndex = -1;
public MddPmdView(Context context) {
this(context, null);
}
public MddPmdView(Context context, AttributeSet attrs) {
this(context, attrs, 0);
}
public MddPmdView(Context context, AttributeSet attrs, int defStyleAttr) {
super(context, attrs, defStyleAttr);
initDatas(context, attrs);
}
private void initDatas(Context context, AttributeSet attrs) {
TypedArray a = context.obtainStyledAttributes(attrs, R.styleable.MddPmdView);
mBgColor = a.getInt(R.styleable.MddPmdView_pmdBgColor, Color.GRAY);
mCirlRadiu = DeviceUtil.dip2px(context, a.getInt(R.styleable.MddPmdView_pmdCirlRadiu, 0));
mStockColor = a.getColor(R.styleable.MddPmdView_pmdStockColor, 0xfff3a33c);
mRadiu = DeviceUtil.dip2px(context, a.getInt(R.styleable.MddPmdView_pmdRadiu, 0));
mStockWidth = DeviceUtil.dip2px(context, a.getInt(R.styleable.MddPmdView_pmdStockWidth, 0));
mPointCount = a.getInt(R.styleable.MddPmdView_pmdPointCount, 0);
duration = a.getInt(R.styleable.MddPmdView_pmdDuration, 300);
a.recycle();
mPaint = new Paint();
mPaint.setAntiAlias(true);
colors.add(Color.RED);
colors.add(Color.YELLOW);
colors.add(Color.BLUE);
colors.add(Color.GREEN);
}
/**
* 计算数据(线上的所有点)
*/
private void loadDatas() {
mPoints.clear();
if (mPointCount <= 0 || mW <= 0 || mH <= 0) {
return;
}
float nCirl = (float) (Math.PI * mRadiu);//圆长度
float nTotalLengh = nCirl + mW * 2 + mH * 2 - mRadiu * 8;//内圈总长度
float nMult = nTotalLengh / mPointCount;
List<Integer> sizes = new ArrayList<>();
//上边
float w1 = mW - mRadiu * 2;
float y = w1 % nMult;//每条边计算完成后的余值
int size = (int) ((w1 - y) / nMult);
sizes.add(size);
PointF nFirstPoint = new PointF();//起始位置,第一个点
nFirstPoint.x = mRadiu;
nFirstPoint.y = mRadiu / 2;
mPoints.add(nFirstPoint);
for (int i = 0; i < size; i++) {
//上边时 第一个点为计算的起点,之后的点Y左边与起点相等,X为根据单位递加
PointF point = new PointF();
point.y = mRadiu / 2;
point.x = mRadiu + (i + 1) * nMult;
mPoints.add(point);
}
float offset = y;//主要用于下一条边计算
double nA = -90;
//右上圆弧
float w2 = nCirl / 4 + y;
y = w2 % nMult;
size = (int) ((w2 - y) / nMult);
sizes.add(size);
for (int i = 0; i < size; i++) {
float nw = nMult - offset;//计算圆弧上的长度
offset = 0;
nA += nw * 90 / (nCirl / 4);//根据长度 计算角度
PointF point = new PointF();
point.x = mW - mRadiu + (float) (mRadiu / 2 * Math.cos(nA * Math.PI / 180));
point.y = mRadiu + (float) (mRadiu / 2 * Math.sin(nA * Math.PI / 180));
mPoints.add(point);
}
offset = y;
//右边
float w3 = mH - mRadiu * 2 + y;
y = w3 % nMult;
size = (int) ((w3 - y) / nMult);
sizes.add(size);
for (int i = 0; i < size; i++) {
PointF point = new PointF();
point.x = mW - mRadiu / 2;
if (i == 0) {
point.y = mRadiu + nMult - offset;
} else {
point.y = mPoints.get(mPoints.size() - 1).y + nMult;
}
mPoints.add(point);
}
offset = y;
//右下圆弧
float w4 = nCirl / 4 + y;
y = w4 % nMult;
size = (int) ((w4 - y) / nMult);
sizes.add(size);
nA = 0;
for (int i = 0; i < size; i++) {
float nw = nMult - offset;
offset = 0;
nA += nw * 90 / (nCirl / 4);//根据长度 计算角度
PointF point = new PointF();
point.x = mW - mRadiu + (float) (mRadiu / 2 * Math.cos(nA * Math.PI / 180));
point.y = mH - mRadiu + (float) (mRadiu / 2 * Math.sin(nA * Math.PI / 180));
mPoints.add(point);
}
offset = y;
//下边
float w5 = mW - mRadiu * 2 + y;
y = w5 % nMult;
size = (int) ((w5 - y) / nMult);
sizes.add(size);
for (int i = 0; i < size; i++) {
PointF point = new PointF();
point.y = mH - mRadiu / 2;
if (i == 0) {
point.x = mW - mRadiu - (nMult - offset);
} else {
point.x = mPoints.get(mPoints.size() - 1).x - nMult;
}
mPoints.add(point);
}
offset = y;
//左下圆弧
float w6 = nCirl / 4 + y;
y = w6 % nMult;
size = (int) ((w6 - y) / nMult);
sizes.add(size);
nA = 90;
for (int i = 0; i < size; i++) {
float nw = nMult - offset;
offset = 0;
nA += nw * 90 / (nCirl / 4);//根据长度 计算角度
PointF point = new PointF();
point.x = mRadiu + (float) (mRadiu / 2 * Math.cos(nA * Math.PI / 180));
point.y = mH - mRadiu + (float) (mRadiu / 2 * Math.sin(nA * Math.PI / 180));
mPoints.add(point);
}
offset = y;
//左边
float w7 = mH - mRadiu * 2 + y;
y = w7 % nMult;
size = (int) ((w7 - y) / nMult);
sizes.add(size);
for (int i = 0; i < size; i++) {
PointF point = new PointF();
point.x = mRadiu / 2;
if (i == 0) {
point.y = mH - mRadiu - (nMult - offset);
} else {
point.y = mPoints.get(mPoints.size() - 1).y - nMult;
}
mPoints.add(point);
}
offset = y;
//左上圆弧
float w8 = nCirl / 4 + y;
y = w8 % nMult;
size = (int) ((w8 - y) / nMult);
sizes.add(size);
nA = 180;
for (int i = 0; i < size; i++) {
float nw = nMult - offset;
offset = 0;
nA += nw * 90 / (nCirl / 4);//根据长度 计算角度
PointF point = new PointF();
point.x = mRadiu + (float) (mRadiu / 2 * Math.cos(nA * Math.PI / 180));
point.y = mRadiu + (float) (mRadiu / 2 * Math.sin(nA * Math.PI / 180));
mPoints.add(point);
}
sizes.clear();
}
/**
* 入口,开始绘制
*
* @param width 总宽
* @param height 总高
*/
public void startRun(int width, int height) {
mW = width;
mH = height;
if (mDisposable != null && !mDisposable.isDisposed()) {
mDisposable.dispose();
}
loadDatas();
mDisposable = Observable.intervalRange(0, Integer.MAX_VALUE, 0, duration, TimeUnit.MILLISECONDS)
.subscribeOn(Schedulers.io()).observeOn(AndroidSchedulers.mainThread())
.subscribe(new Consumer<Long>() {
@Override
public void accept(final Long aLong) throws Exception {
try {
mRunIndex += 1;
invalidate();
} catch (Exception e) {
Log.e("Tag", Log.getStackTraceString(e));
}
}
});
}
@Override
protected void onDraw(Canvas canvas) {
super.onDraw(canvas);
if (mPoints.isEmpty()) {
//无数据时不绘制
return;
}
mPaint.setColor(mBgColor);
mPaint.setStyle(Paint.Style.FILL);
canvas.drawRoundRect(new RectF(0, 0, mW, mH), mRadiu, mRadiu, mPaint);//画背景
mPaint.setColor(mStockColor);
mPaint.setStyle(Paint.Style.STROKE);
mPaint.setStrokeWidth(mStockWidth);
RectF rect = new RectF(mRadiu / 2, mRadiu / 2, mW - mRadiu / 2, mH - mRadiu / 2);
canvas.drawRoundRect(rect, mRadiu / 2, mRadiu / 2, mPaint);
//画边线,此时rect的四条边的值,为实际效果4条边的中心值,即为边线宽度1时的位置,大于1时则以1为中心
mPaint.setStyle(Paint.Style.FILL);
for (int i = 0; i < mPoints.size(); i++) {
//轮询切换颜色 并且每次切换时,修改对应坐标点绘制颜色的下标,以达到一种动态的效果
mPaint.setColor(colors.get((i + mRunIndex) % colors.size()));
canvas.drawCircle(mPoints.get(i).x, mPoints.get(i).y, mCirlRadiu, mPaint);
}
}
@Override
protected void onDetachedFromWindow() {
super.onDetachedFromWindow();
if (mDisposable != null && !mDisposable.isDisposed()) {
mDisposable.dispose();
}
}
public MddPmdView setRadiu(float radiu) {
this.mRadiu = radiu;
return MddPmdView.this;
}
public MddPmdView setStockWidth(float stockWidth) {
this.mStockWidth = stockWidth;
return MddPmdView.this;
}
public MddPmdView setCirlRadiu(float cirlRadiu) {
this.mCirlRadiu = cirlRadiu;
return MddPmdView.this;
}
public MddPmdView setBgColor(int bgColor) {
this.mBgColor = bgColor;
return MddPmdView.this;
}
public MddPmdView setStockColor(int stockColor) {
this.mStockColor = stockColor;
return MddPmdView.this;
}
public MddPmdView setPointCount(int count) {
this.mPointCount = count;
return MddPmdView.this;
}
public void setColors(List<Integer> colors) {
this.colors.clear();
if (colors != null && !colors.isEmpty()) {
this.colors.addAll(colors);
}
}
}
