图片加载控件glide





基本用法
        //（1）加载网络图片
        tvGlide1.setText("（1）加载网络图片");
        Glide.with(this).load("http://img1.imgtn.bdimg.com/it/u=2615772929,948758168&fm=21&gp=0.jpg").into(ivGlide1);

        //（2）加载资源图片
        tvGlide2.setText("（2）加载资源图片");
        Glide.with(this).load(R.drawable.atguigu_logo).into(ivGlide2);

        //（3）加载本地图片
        tvGlide3.setText("（3）加载本地图片");
        String path = Environment.getExternalStorageDirectory() + "/meinv1.jpg";
        File file = new File(path);
        Uri uri = Uri.fromFile(file);
        Glide.with(this).load(uri).into(ivGlide3);

        // （4）加载网络gif
        tvGlide4.setText("（4）加载网络gif");
        String gifUrl = "http://b.hiphotos.baidu.com/zhidao/pic/item/faedab64034f78f066abccc57b310a55b3191c67.jpg";
        Glide.with(this).load(gifUrl).placeholder(R.mipmap.ic_launcher).into(ivGlide4);

        // （5）加载资源gif
        tvGlide5.setText("（5）加载资源gif");
        Glide.with(this).load(R.drawable.loading).asGif().placeholder(R.mipmap.ic_launcher).into(ivGlide5);

        //（6）加载本地gif
        tvGlide6.setText("（6）加载本地gif");
        String gifPath = Environment.getExternalStorageDirectory() + "/meinv2.jpg";
        File gifFile = new File(gifPath);
        Glide.with(this).load(gifFile).placeholder(R.mipmap.ic_launcher).into(ivGlide6);

        //（7）加载本地小视频和快照
        tvGlide7.setText("（7）加载本地小视频和快照");
        String videoPath = Environment.getExternalStorageDirectory() + "/video.mp4";
        File videoFile = new File(videoPath);
        Glide.with(this).load(Uri.fromFile(videoFile)).placeholder(R.mipmap.ic_launcher).into(ivGlide7);

        //（8）设置缩略图比例,然后，先加载缩略图，再加载原图
        tvGlide8.setText("（8）设置缩略图比例,然后，先加载缩略图，再加载原图");
        String urlPath = Environment.getExternalStorageDirectory() + "/meinv1.jpg";
        Glide.with(this).load(new File(urlPath)).thumbnail(0.1f).centerCrop().placeholder(R.mipmap.ic_launcher).into(ivGlide8);

        //（9）先建立一个缩略图对象，然后，先加载缩略图，再加载原图
        tvGlide9.setText("（9）先建立一个缩略图对象，然后，先加载缩略图，再加载原图");
        DrawableRequestBuilder thumbnailRequest = Glide.with(this).load(new File(urlPath));
        Glide.with(this).load(Uri.fromFile(videoFile)).thumbnail(thumbnailRequest).centerCrop().placeholder(R.mipmap.ic_launcher).into(ivGlide9);




图片加载到recyclerview中
public class GlideRecyclerviewActivity extends Activity {

    @Bind(R.id.tv_title)
    TextView tvTitle;
    @Bind(R.id.rv_glide)
    RecyclerView rvGlide;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_glide_recyclerview);
        ButterKnife.bind(this);

        initData();
    }

    private void initData() {
        tvTitle.setText("Glide在RecyclerView中加载图片");

        // 初始化Recyclerview
        GlideRecyclerviewAdapter glideRecyclerviewAdapter = new GlideRecyclerviewAdapter(this);
        rvGlide.setAdapter(glideRecyclerviewAdapter);
        rvGlide.setLayoutManager(new LinearLayoutManager(this,LinearLayoutManager.VERTICAL,false));
    }
}

public class GlideRecyclerviewAdapter extends RecyclerView.Adapter<GlideRecyclerviewAdapter.ViewHolder> {
    private Context mContext;
    /**
     * 准备数据
     */
    String[] mDatas = new String[]{
            "http://b337.photo.store.qq.com/psb?/V10FcMmY1Ttz2o/7.fo01qLQ*SI59*E2Wq.j82HuPfes*efgiyEi7mrJdk!/b/dLHI5cioAQAA&bo=VQOAAgAAAAABB*Q!&rf=viewer_4",
            "http://b118.photo.store.qq.com/psb?/V10FcMmY2gHuOI/8*6eK6PHCNTx1utXooId*KAWgwPTllj.b6uBg4McCwM!/b/dAt8W0YJJAAA&bo=VQOAAgAAAAABB*Q!&rf=viewer_4",
            "http://img1.imgtn.bdimg.com/it/u=488611129,2377736106&fm=11&gp=0.jpg",
            "http://img2.imgtn.bdimg.com/it/u=3398443685,2594061265&fm=11&gp=0.jpg",
            "http://img3.imgtn.bdimg.com/it/u=2271902832,1324672617&fm=21&gp=0.jpg",
            "http://a.hiphotos.baidu.com/image/h%3D200/sign=d20242020e24ab18ff16e63705fae69a/267f9e2f070828389f547b30bf99a9014c08f1bd.jpg",
            "http://img5.duitang.com/uploads/item/201406/28/20140628132554_UNE4n.thumb.700_0.jpeg",
            "http://cdn.duitang.com/uploads/item/201309/22/20130922202150_ntvAB.thumb.600_0.jpeg",
            "http://cdn.duitang.com/uploads/item/201208/04/20120804013554_yRGfe.jpeg",
            "http://img5.imgtn.bdimg.com/it/u=2050390856,2980742959&fm=21&gp=0.jpg",
            "http://img3.duitang.com/uploads/item/201501/23/20150123204322_N8nw5.jpeg",
            "http://img4q.duitang.com/uploads/item/201505/09/20150509204813_nEwxF.jpeg",
            "http://img1.imgtn.bdimg.com/it/u=2432702027,3704029716&fm=21&gp=0.jpg",
            "http://i.imgur.com/syELajx.jpg",
            "http://i.imgur.com/COzBnru.jpg",
            "http://i.imgur.com1111/Z3QjilA.jpg"
    };

    public GlideRecyclerviewAdapter(Context context) {
        mContext = context;
    }

    @Override
    public ViewHolder onCreateViewHolder(ViewGroup parent, int viewType) {
        View itemview = View.inflate(mContext, R.layout.item_glide_recyclerview, null);
        return new ViewHolder(itemview);
    }

    @Override
    public void onBindViewHolder(ViewHolder holder, int position) {
        // 获取当前item数据

        // 显示数据
        int width = (int) TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_DIP, 200, mContext.getResources().getDisplayMetrics());
        int height = (int) TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_DIP, 200f, mContext.getResources().getDisplayMetrics());

        Glide.with(mContext)
                .load(mDatas[position])
                .placeholder(R.mipmap.ic_launcher) //占位图
                .error(R.mipmap.ic_launcher)  //出错的占位图
                .override(width, height) //图片显示的分辨率 ，像素值 可以转化为DP再设置
                .animate(R.anim.glide_anim)
                .centerCrop()
                .fitCenter()
                .into(holder.image);
    }

    @Override
    public int getItemCount() {
        return mDatas == null ? 0 : mDatas.length;
    }

    static class ViewHolder extends RecyclerView.ViewHolder {

        @Bind(R.id.iv_glide_recyclerview)
        ImageView image;

        public ViewHolder(View itemView) {
            super(itemView);

            ButterKnife.bind(this,itemView);
        }
    }
}



图形变换
import android.content.Context;
import android.graphics.Color;
import android.graphics.PointF;
import android.support.v7.widget.RecyclerView;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ImageView;
import android.widget.TextView;

import com.atguigu.android.R;
import com.atguigu.android.picasso.Utils;
import com.bumptech.glide.Glide;
import com.bumptech.glide.load.resource.bitmap.CenterCrop;

import java.util.ArrayList;
import java.util.List;

import butterknife.Bind;
import butterknife.ButterKnife;
import jp.wasabeef.glide.transformations.BlurTransformation;
import jp.wasabeef.glide.transformations.ColorFilterTransformation;
import jp.wasabeef.glide.transformations.CropCircleTransformation;
import jp.wasabeef.glide.transformations.CropSquareTransformation;
import jp.wasabeef.glide.transformations.CropTransformation;
import jp.wasabeef.glide.transformations.GrayscaleTransformation;
import jp.wasabeef.glide.transformations.MaskTransformation;
import jp.wasabeef.glide.transformations.RoundedCornersTransformation;
import jp.wasabeef.glide.transformations.gpu.BrightnessFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.ContrastFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.InvertFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.KuwaharaFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.PixelationFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.SepiaFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.SketchFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.SwirlFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.ToonFilterTransformation;
import jp.wasabeef.glide.transformations.gpu.VignetteFilterTransformation;

/**
 * Created by Administrator on 2016/10/28.
 */

public class GlideTranformationsAdapter extends RecyclerView.Adapter<GlideTranformationsAdapter.ViewHolder> {

    private Context mContext;
    private List<String> mData = new ArrayList<>();

    public GlideTranformationsAdapter(Context context) {
        mContext = context;
        for (int i = 1; i <= 21; i++) {
            mData.add(i + "");
        }
    }

    @Override
    public ViewHolder onCreateViewHolder(ViewGroup parent, int viewType) {
        View itemview = View.inflate(mContext, R.layout.item_glide_tranformations, null);
        return new ViewHolder(itemview);
    }

    @Override
    public void onBindViewHolder(ViewHolder holder, int position) {

        // 设置名称
        holder.name.setText("item" + (position + 1));

        int integer = Integer.parseInt(mData.get(position));

        switch (integer) {
            case 1: {
                int width = Utils.dip2px(mContext, 133.33f);
                int height = Utils.dip2px(mContext, 126.33f);
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .override(width, height)
                        .bitmapTransform(new CenterCrop(mContext),
                                new MaskTransformation(mContext, R.drawable.mask_starfish))
                        .into(holder.image);
                break;
            }
            case 2: {
                int width = Utils.dip2px(mContext, 150.0f);
                int height = Utils.dip2px(mContext, 100.0f);
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .override(width, height)
                        .bitmapTransform(new CenterCrop(mContext),
                                new MaskTransformation(mContext, R.drawable.mask_chat_right))
                        .into(holder.image);
                break;
            }
            case 3:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(
                                new CropTransformation(mContext, 300, 100, CropTransformation.CropType.TOP))
                        .into(holder.image);
                break;
            case 4:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(new CropTransformation(mContext, 300, 100))
                        .into(holder.image);
                break;
            case 5:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(
                                new CropTransformation(mContext, 300, 100, CropTransformation.CropType.BOTTOM))
                        .into(holder.image);

                break;
            case 6:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(new CropSquareTransformation(mContext))
                        .into(holder.image);
                break;
            case 7:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(new CropCircleTransformation(mContext))
                        .into(holder.image);
                break;
            case 8:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(new ColorFilterTransformation(mContext, Color.argb(80, 255, 0, 0)))
                        .into(holder.image);
                break;
            case 9:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(new GrayscaleTransformation(mContext))
                        .into(holder.image);
                break;
            case 10:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(new RoundedCornersTransformation(mContext, 30, 0,
                                RoundedCornersTransformation.CornerType.BOTTOM))
                        .into(holder.image);
                break;
            case 11:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new BlurTransformation(mContext, 25))
                        .into(holder.image);
                break;
            case 12:
                Glide.with(mContext)
                        .load(R.drawable.demo)
                        .bitmapTransform(new ToonFilterTransformation(mContext))
                        .into(holder.image);
                break;
            case 13:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new SepiaFilterTransformation(mContext))
                        .into(holder.image);
                break;
            case 14:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new ContrastFilterTransformation(mContext, 2.0f))
                        .into(holder.image);
                break;
            case 15:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new InvertFilterTransformation(mContext))
                        .into(holder.image);
                break;
            case 16:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new PixelationFilterTransformation(mContext, 20))
                        .into(holder.image);
                break;
            case 17:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new SketchFilterTransformation(mContext))
                        .into(holder.image);
                break;
            case 18:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(
                                new SwirlFilterTransformation(mContext, 0.5f, 1.0f, new PointF(0.5f, 0.5f)))
                        .into(holder.image);
                break;
            case 19:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new BrightnessFilterTransformation(mContext, 0.5f))
                        .into(holder.image);
                break;
            case 20:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new KuwaharaFilterTransformation(mContext, 25))
                        .into(holder.image);
                break;
            case 21:
                Glide.with(mContext)
                        .load(R.drawable.check)
                        .bitmapTransform(new VignetteFilterTransformation(mContext, new PointF(0.5f, 0.5f),
                                new float[]{0.0f, 0.0f, 0.0f}, 0f, 0.75f))
                        .into(holder.image);
                break;
        }
    }

    @Override
    public int getItemCount() {
        return mData.size();
    }

    static class ViewHolder extends RecyclerView.ViewHolder {
        @Bind(R.id.iv_glide_tranfromations)
        ImageView image;

        @Bind(R.id.tv_glide_name)
        TextView name;

        public ViewHolder(View itemView) {
            super(itemView);

            ButterKnife.bind(this, itemView);
        }
    }
}
