实现一个jstack
在聊Jstack得工作原理前呢，不如让我们先写一个简单的jstack玩玩。不用怕，很简单的,就几行代码的事，看：
public class MyJstack {
public static void main(String[] args)throws Exception {
VirtualMachine virtualMachine = VirtualMachine.attach("6361");
HotSpotVirtualMachine hotSpotVirtualMachine = (HotSpotVirtualMachine)virtualMachine;
InputStream inputStream = hotSpotVirtualMachine.remoteDataDump(new String[]{});
byte[] buff = new byte[256];
int len;
do {
len = inputStream.read(buff);
if (len > 0) {
String respone = new String(buff, 0, len, "UTF-8");
System.out.print(respone);
}
} while(len > 0);
inputStream.close();
virtualMachine.detach();
}
}
很简单吧，贴到你的开发环境里，运行就好了，别忘了把6361这个进程号换成你自己的Java进程号哦。
实现原理
jstack有两种实现方式，一种是基于attach api,其实现可以在tools.jar里找到；另一种是基于SA的实现，它被放在了sa-jdi.jar里。如果你通过idea搜索Jstack类，你会看到tools.jar和sa-jdi.jar各有一个Jstack类。
本文呢，就通过分析attch api的源码，来了解jstack的工作原理。
jstack本地源码实现
我们来看一下HotSpotVirtualMachine的remoteDataDump方法：
public InputStream remoteDataDump(Object... var1) throws IOException {
return this.executeCommand("threaddump", var1);
}
他是在执行一个叫threaddump的命令。沿着这个executeCommand方法继续往里追，会发现他是调用了如下方法：
InputStream execute(String var1, Object... var2) throws AgentLoadException, IOException {
assert var2.length <= 3;
String var3;
synchronized(this) {
if (this.path == null) {
throw new IOException("Detached from target VM");
}
var3 = this.path;
}
int var4 = socket();
try {
connect(var4, var3);
} catch (IOException var9) {
close(var4);
throw var9;
}
IOException var5 = null;
try {
this.writeString(var4, "1");
this.writeString(var4, var1);
var1参数就是我们的threaddump指令，不难看出，这个方法是建立了一个socket连接，然后将threaddump指令发送给另一端，即我们要检查的jvm进程。
注意：限于篇幅我并没有贴整个方法代码。execute是HotSpotVirtualMachine的抽象方法，不同平台的jdk有不同的execute方法的实现，我这里的代码是mac下的execute实现，位于BsdVirtualMachine类中。
通过jtack本地源代码，我们大致可以粗略的认为：jstack就是通过与指定的jvm进程建立socket连接，然后发送指令，最后将jvm进程返回的内容打印出来。
JVM的源码实现
了解了jstack的本地源码，我们在看看jvm进程是如何处理的。
当我们使用Java命令启动jvm进程时，Java命令会加载虚拟机共享库，然后执行共享库里的JNI_CreateJavaVM方法完成虚拟机的创建，在JNI_CreateJavaVM方法里会调用如下代码，完成具体的一个创建过程：
result = Threads::create_vm((JavaVMInitArgs*) args, &can_try_again);
如果你有心，或许会留意到，在你启动一个jvm进程时，即便你什么线程也没创建，你用jstack查看还是有很多的线程，如：Signal Dispatcher，VM Thread，Attach Listener等等。当过阅读本文，你会了解到这三个线程的作用。
01 VM Thread线程
Threads::create_vm这个方法很长，接下来咱们跳出一些重要的段落，来分析分析。
// Create the VMThread
{ TraceTime timer("Start VMThread", TraceStartupTime);
VMThread::create();//创建Thread对象
Thread* vmthread = VMThread::vm_thread();
if (!os::create_thread(vmthread, os::vm_thread))//调用操作系统api创建线程
vm_exit_during_initialization("Cannot create VM thread. Out of system resources.");
// Wait for the VM thread to become ready, and VMThread::run to initialize
// Monitors can have spurious returns, must always check another state flag
{
MutexLocker ml(Notify_lock);
os::start_thread(vmthread);//启动线程
while (vmthread->active_handles() == NULL) {
Notify_lock->wait();
}
}
}
通过注释，你也知道，这一段代码是从来创建VM Thread线程的。VMThread::create()完成了对现成的命名工作，代码如下：
void VMThread::create() {
assert(vm_thread() == NULL, "we can only allocate one VMThread");
_vm_thread = new VMThread();
// Create VM operation queue
_vm_queue = new VMOperationQueue();
guarantee(_vm_queue != NULL, "just checking");
_terminate_lock = new Monitor(Mutex::safepoint, "VMThread::_terminate_lock", true);
if (UsePerfData) {
// jvmstat performance counters
Thread* THREAD = Thread::current();
_perf_accumulated_vm_operation_time =
PerfDataManager::create_counter(SUN_THREADS, "vmOperationTime",
PerfData::U_Ticks, CHECK);
}
}
VMThread::VMThread() : NamedThread() {
set_name("VM Thread");
}
通过new VMThread()创建线程对象，在VMThread的构造方法里将线程命名成VM Thread，这就是我们jstack看到的VM Thread线程,同时还为这个线程创建了一个叫VMOperationQueue的队列。
至于VM Thread线程的作用，我们留到最后再说。
02 Signal Dispatcher线程
继续沿着 Threads::create_vm方法往下看，我们会看到如下代码：
// Signal Dispatcher needs to be started before VMInit event is posted
os::signal_init();
这一句代码实现了Signal Dispatcher线程的创建，进入到signal_init()方法看看:
void os::signal_init() {
if (!ReduceSignalUsage) {
// Setup JavaThread for processing signals
EXCEPTION_MARK;
Klass* k = SystemDictionary::resolve_or_fail(vmSymbols::java_lang_Thread(), true, CHECK);
instanceKlassHandle klass (THREAD, k);
instanceHandle thread_oop = klass->allocate_instance_handle(CHECK);
const char thread_name[] = "Signal Dispatcher";
Handle string = java_lang_String::create_from_str(thread_name, CHECK);
// Initialize thread_oop to put it into the system threadGroup
Handle thread_group (THREAD, Universe::system_thread_group());
JavaValue result(T_VOID);
JavaCalls::call_special(&result, thread_oop,
klass,
vmSymbols::object_initializer_name(),
vmSymbols::threadgroup_string_void_signature(),
thread_group,
string,
CHECK);
KlassHandle group(THREAD, SystemDictionary::ThreadGroup_klass());
JavaCalls::call_special(&result,
thread_group,
group,
vmSymbols::add_method_name(),
vmSymbols::thread_void_signature(),
thread_oop, // ARG 1
CHECK);
os::signal_init_pd();
{ MutexLocker mu(Threads_lock);
JavaThread* signal_thread = new JavaThread(&signal_thread_entry);
// At this point it may be possible that no osthread was created for the
// JavaThread due to lack of memory. We would have to throw an exception
// in that case. However, since this must work and we do not allow
// exceptions anyway, check and abort if this fails.
if (signal_thread == NULL || signal_thread->osthread() == NULL) {
vm_exit_during_initialization("java.lang.OutOfMemoryError",
"unable to create new native thread");
}
java_lang_Thread::set_thread(thread_oop(), signal_thread);
java_lang_Thread::set_priority(thread_oop(), NearMaxPriority);
java_lang_Thread::set_daemon(thread_oop());
signal_thread->set_threadObj(thread_oop());
Threads::add(signal_thread);
Thread::start(signal_thread);
}
// Handle ^BREAK
os::signal(SIGBREAK, os::user_handler());
}
}
在这个方法里，我们可以看到要创建的线程名字:Signal Dispatcher，以及线程启动后调用的方法signal_thread_entry。（方法较长，看重点就好，没必要每句话都扣清楚）。
有了对上边代码的分析，我们只需要看看signal_thread_entry方法，就知道Signal Dispatcher线程的作用了。
static void signal_thread_entry(JavaThread* thread, TRAPS) {
os::set_priority(thread, NearMaxPriority);
while (true) {
int sig;
{
// FIXME : Currently we have not decieded what should be the status
// for this java thread blocked here. Once we decide about
// that we should fix this.
sig = os::signal_wait();//等待获取信号
}
if (sig == os::sigexitnum_pd()) {
// Terminate the signal thread
return;
}
switch (sig) {
case SIGBREAK: {
// Check if the signal is a trigger to start the Attach Listener - in that
// case don't print stack traces.
if (!DisableAttachMechanism && AttachListener::is_init_trigger()) {
continue;
}
// Print stack traces
// Any SIGBREAK operations added here should make sure to flush
// the output stream (e.g. tty->flush()) after output. See 4803766.
// Each module also prints an extra carriage return after its output.
VM_PrintThreads op;
VMThread::execute(&op);
VM_PrintJNI jni_op;
VMThread::execute(&jni_op);
VM_FindDeadlocks op1(tty);
VMThread::execute(&op1);
Universe::print_heap_at_SIGBREAK();
if (PrintClassHistogram) {
VM_GC_HeapInspection op1(gclog_or_tty, true /* force full GC before heap inspection */);
VMThread::execute(&op1);
}
if (JvmtiExport::should_post_data_dump()) {
JvmtiExport::post_data_dump();
}
break;
这个方法里调用os::signal_wait()获取传给该jvm进程的信号，然后对信号进行处理。
说下case SIGBREAK里的处理逻辑，当接收到SIGBREAK信号时，会先判断是否禁止Attach机制，如果没有禁止，会调用AttachListener::is_init_trigger()方法触发Attach Listener线程的初始化.如果attach机制被禁用，则会创建VM_PrintThreads、VM_PrintJNI、VM_FindDeadlocks等代表某一个操作的对象，通过VMThread::execute()方法扔到VM Thread线程的VMOperationQueue队列。
03 Attach Listener线程
继续沿着 Threads::create_vm方法往下看，在紧挨着启动Signal Dispatcher线程的下边，就是启动Attach Listener线程的语句：
// Start Attach Listener if +StartAttachListener or it can't be started lazily
if (!DisableAttachMechanism) {
AttachListener::vm_start();
if (StartAttachListener || AttachListener::init_at_startup()) {
AttachListener::init();
}
}
重点就在AttachListener::init()方法里：
// Starts the Attach Listener thread
void AttachListener::init() {
EXCEPTION_MARK;
Klass* k = SystemDictionary::resolve_or_fail(vmSymbols::java_lang_Thread(), true, CHECK);
instanceKlassHandle klass (THREAD, k);
instanceHandle thread_oop = klass->allocate_instance_handle(CHECK);
const char thread_name[] = "Attach Listener";
Handle string = java_lang_String::create_from_str(thread_name, CHECK);
// Initialize thread_oop to put it into the system threadGroup
Handle thread_group (THREAD, Universe::system_thread_group());
JavaValue result(T_VOID);
JavaCalls::call_special(&result, thread_oop,
klass,
vmSymbols::object_initializer_name(),
vmSymbols::threadgroup_string_void_signature(),
thread_group,
string,
THREAD);
if (HAS_PENDING_EXCEPTION) {
tty->print_cr("Exception in VM (AttachListener::init) : ");
java_lang_Throwable::print(PENDING_EXCEPTION, tty);
tty->cr();
CLEAR_PENDING_EXCEPTION;
return;
}
KlassHandle group(THREAD, SystemDictionary::ThreadGroup_klass());
JavaCalls::call_special(&result,
thread_group,
group,
vmSymbols::add_method_name(),
vmSymbols::thread_void_signature(),
thread_oop, // ARG 1
THREAD);
if (HAS_PENDING_EXCEPTION) {
tty->print_cr("Exception in VM (AttachListener::init) : ");
java_lang_Throwable::print(PENDING_EXCEPTION, tty);
tty->cr();
CLEAR_PENDING_EXCEPTION;
return;
}
{ MutexLocker mu(Threads_lock);
JavaThread* listener_thread = new JavaThread(&attach_listener_thread_entry);
// Check that thread and osthread were created
if (listener_thread == NULL || listener_thread->osthread() == NULL) {
vm_exit_during_initialization("java.lang.OutOfMemoryError",
"unable to create new native thread");
}
java_lang_Thread::set_thread(thread_oop(), listener_thread);
java_lang_Thread::set_daemon(thread_oop());
listener_thread->set_threadObj(thread_oop());
Threads::add(listener_thread);
Thread::start(listener_thread);
}
}
我们可以通过代码看出其创建了一个叫Attach Listener的线程，线程执行的逻辑封装在了attach_listener_thread_entry方法里。Attach Listener线程的作用，我们看看attach_listener_thread_entry方法便知:
static void attach_listener_thread_entry(JavaThread* thread, TRAPS) {
os::set_priority(thread, NearMaxPriority);
thread->record_stack_base_and_size();
if (AttachListener::pd_init() != 0) {
return;
}
AttachListener::set_initialized();
for (;;) {
AttachOperation* op = AttachListener::dequeue();//从队列里获取操作对象
if (op == NULL) {
return; // dequeue failed or shutdown
}
ResourceMark rm;
bufferedStream st;
jint res = JNI_OK;
// handle special detachall operation
if (strcmp(op->name(), AttachOperation::detachall_operation_name()) == 0) {
AttachListener::detachall();
} else {
// find the function to dispatch too
AttachOperationFunctionInfo* info = NULL;
for (int i=0; funcs[i].name != NULL; i++) {
const char* name = funcs[i].name;
assert(strlen(name) <= AttachOperation::name_length_max, "operation <= name_length_max");
if (strcmp(op->name(), name) == 0) {
info = &(funcs[i]);
break;
}
}
// check for platform dependent attach operation
if (info == NULL) {
info = AttachListener::pd_find_operation(op->name());
}
if (info != NULL) {
// dispatch to the function that implements this operation
res = (info->func)(op, &st);//执行操作对象
} else {
st.print("Operation %s not recognized!", op->name());
res = JNI_ERR;
}
}
// operation complete - send result and output to client
op->complete(res, &st);
}
}
方法很长，我把重点挑出来分析。首先我们看看调用AttachListener::pd_init()完了什么：
int AttachListener::pd_init() {
JavaThread* thread = JavaThread::current();
ThreadBlockInVM tbivm(thread);
thread->set_suspend_equivalent();
// cleared by handle_special_suspend_equivalent_condition() or
// java_suspend_self() via check_and_wait_while_suspended()
int ret_code = LinuxAttachListener::init();
// were we externally suspended while we were waiting?
thread->check_and_wait_while_suspended();
return ret_code;
}
int LinuxAttachListener::init() {
char path[UNIX_PATH_MAX]; // socket file
char initial_path[UNIX_PATH_MAX]; // socket file during setup
int listener; // listener socket (file descriptor)
// register function to cleanup
::atexit(listener_cleanup);
int n = snprintf(path, UNIX_PATH_MAX, "%s/.java_pid%d",
os::get_temp_directory(), os::current_process_id());
if (n < (int)UNIX_PATH_MAX) {
n = snprintf(initial_path, UNIX_PATH_MAX, "%s.tmp", path);
}
if (n >= (int)UNIX_PATH_MAX) {
return -1;
}
// create the listener socket
listener = ::socket(PF_UNIX, SOCK_STREAM, 0);//创建套接字
if (listener == -1) {
return -1;
}
// bind socket
struct sockaddr_un addr;
addr.sun_family = AF_UNIX;
strcpy(addr.sun_path, initial_path);
::unlink(initial_path);
int res = ::bind(listener, (struct sockaddr*)&addr, sizeof(addr));//绑定地址
if (res == -1) {
::close(listener);
return -1;
}
// put in listen mode, set permissions, and rename into place
res = ::listen(listener, 5);//发起监听
if (res == 0) {
RESTARTABLE(::chmod(initial_path, S_IREAD|S_IWRITE), res);
if (res == 0) {
res = ::rename(initial_path, path);
}
}
if (res == -1) {
::close(listener);
::unlink(initial_path);
return -1;
}
set_path(path);
set_listener(listener);
return 0;
}
不难发现，AttachListener::pd_init()方法又调用了LinuxAttachListener::init()方法，完成了对套接字的创建和监听。这与jstack本地代码建立socket连接发送命令，不谋而合。
再就是有一个for死循环，不停地调用AttachOperation* op = AttachListener::dequeue();获取操作对象。如果进入到AttachListener::dequeue()方法看一看，其实就是在读上边监听的套接字，我这里就不贴源码了。
在这个死循环里，我们重点看看如下代码:
// find the function to dispatch too
AttachOperationFunctionInfo* info = NULL;
for (int i=0; funcs[i].name != NULL; i++) {
const char* name = funcs[i].name;
assert(strlen(name) <= AttachOperation::name_length_max, "operation <= name_length_max");
if (strcmp(op->name(), name) == 0) {
info = &(funcs[i]);
break;
}
}
// check for platform dependent attach operation
if (info == NULL) {
info = AttachListener::pd_find_operation(op->name());
}
if (info != NULL) {
// dispatch to the function that implements this operation
res = (info->func)(op, &st);//调动方法
} else {
st.print("Operation %s not recognized!", op->name());
res = JNI_ERR;
}
}
// operation complete - send result and output to client
op->complete(res, &st);
这个for循环会遍历funcs数组，然后根据从队列里拿到的AttachOperation对象的name来找到一个匹配的AttachOperationFunctionInfo对象，然后调用其func方法。
看到这里你或许很多疑惑，当然看看funcs数组里的东西，就开朗了：
static AttachOperationFunctionInfo funcs[] = {
{ "agentProperties", get_agent_properties },
{ "datadump", data_dump },
{ "dumpheap", dump_heap },
{ "load", JvmtiExport::load_agent_library },
{ "properties", get_system_properties },
{ "threaddump", thread_dump },
{ "inspectheap", heap_inspection },
{ "setflag", set_flag },
{ "printflag", print_flag },
{ "jcmd", jcmd },
{ NULL, NULL }
};
有没有看到上文中我们提到的threaddump命令。jstack通过与jvm进程建立socket连接，然后向jvm进程发送threaddump指令。上文说道调用AttachOperationFunctionInfo对象的func方法处理指令，其实就是调用了thread_dump方法，针对threaddump命令来说。
坚持，马上就要说完了。来看看thread_dump方法干了些啥吧:
// Implementation of "threaddump" command - essentially a remote ctrl-break
// See also: ThreadDumpDCmd class
//
static jint thread_dump(AttachOperation* op, outputStream* out) {
bool print_concurrent_locks = false;
if (op->arg(0) != NULL && strcmp(op->arg(0), "-l") == 0) {
print_concurrent_locks = true;
}
// thread stacks
VM_PrintThreads op1(out, print_concurrent_locks);
VMThread::execute(&op1);
// JNI global handles
VM_PrintJNI op2(out);
VMThread::execute(&op2);
// Deadlock detection
VM_FindDeadlocks op3(out);
VMThread::execute(&op3);
return JNI_OK;
}
很简单，创建了VM_PrintThreads、VM_PrintJNI、VM_FindDeadlocks三个对象，扔给了VM Thread线程的队列。
说到这里，VM Thread线程的作用，应该真相大白了，就是读取队列，然后执行相应的操作。有兴趣你可以继续追进去看看源代码，我这里就不追下去了。
总结
看了这么多代码，确实很头疼，总结下吧。
jstack是通过与jvm进程建立socket连接，然后发送指令来实现相关操作。
jvm的Attach Listener线程监听套接字，读取jstack发来的指令，然后将相关的操作扔给VM Thread线程来执行，最后返回给jstack。
在jvm启动的时候，如果没有指定StartAttachListener，Attach Listener线程是不会启动的，在Signal Dispatcher线程收到SIGBREAK信号时，会调用 AttachListener::is_init_trigger（）通过调用用AttachListener::init（）启动了Attach Listener 线程。
加入知识星球，可以有更多的交流，更多的学习和更快的提高。
来源：oschina
链接：https://my.oschina.net/u/4375111/blog/3989755
