/// <summary>
/// 步骤进度控件
/// </summary>
[ToolboxItem(true)]
[DefaultProperty("Items")]
[DefaultEvent("StepIndexChanged")]
[Description("步骤进度控件")]
public partial class StepProgressExt : Control
{
public delegate void StepEventHandler(object sender, StepItemEventArgs e);
#region
private event StepEventHandler stepIndexChanged;
/// <summary>
/// 步骤进度更改事件
/// </summary>
[Description("步骤进度更改事件")]
public event StepEventHandler StepIndexChanged
{
add { this.stepIndexChanged += value; }
remove { this.stepIndexChanged -= value; }
}
private StepOrientation orientation = StepOrientation.HorizontalTop;
/// <summary>
/// 步骤控件方向位置
/// </summary>
[DefaultValue(StepOrientation.HorizontalTop)]
[Description("步骤控件方向位置")]
public StepOrientation Orientation
{
get { return this.orientation; }
set
{
if (this.orientation == value)
return;
this.orientation = value;
this.InitializeSlideValueRectangleFs();
this.Invalidate();
}
}
private int stepSpace = 80;
/// <summary>
/// 步骤选项间距
/// </summary>
[DefaultValue(80)]
[Description("步骤选项间距")]
public int StepSpace
{
get { return this.stepSpace; }
set
{
if (this.stepSpace == value || value < 0)
return;
this.stepSpace = value;
this.InitializeSlideValueRectangleFs();
this.Invalidate();
}
}
private int stepLine = 2;
/// <summary>
/// 步骤线条大小
/// </summary>
[DefaultValue(2)]
[Description("步骤线条大小")]
public int StepLine
{
get { return this.stepLine; }
set
{
if (this.stepLine == value || value < 0)
return;
this.stepLine = value;
this.InitializeSlideValueRectangleFs();
this.Invalidate();
}
}
#region 步骤选项
private int stepRadius = 12;
/// <summary>
/// 步骤选项圆形半径
/// </summary>
[DefaultValue(12)]
[Description("步骤选项圆形半径")]
public int StepRadius
{
get { return this.stepRadius; }
set
{
if (this.stepRadius == value || value < 0)
return;
this.stepRadius = value;
this.InitializeSlideValueRectangleFs();
this.Invalidate();
}
}
private Color normalBackColor = Color.FromArgb(90, 255, 192, 203);
/// <summary>
/// 步骤默认背景颜色(全局配置)
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "90, 255, 192, 203")]
[Description("步骤默认背景颜色(全局配置)")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color NormalBackColor
{
get { return this.normalBackColor; }
set
{
if (this.normalBackColor == value)
return;
this.normalBackColor = value;
this.Invalidate();
}
}
private Color finishBackColor = Color.FromArgb(255, 255, 255);
/// <summary>
/// 步骤完成背景颜色(全局配置)
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "255, 255, 255")]
[Description("步骤完成背景颜色(全局配置)")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color FinishBackColor
{
get { return this.finishBackColor; }
set
{
if (this.finishBackColor == value)
return;
this.finishBackColor = value;
this.Invalidate();
}
}
private Color proceedColor = Color.FromArgb(179, 255, 160, 122);
/// <summary>
/// 步骤开始颜色(全局配置)
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "179, 255, 160, 122")]
[Description("步骤开始颜色(全局配置)")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color ProceedColor
{
get { return this.proceedColor; }
set
{
if (this.proceedColor == value)
return;
this.proceedColor = value;
this.Invalidate();
}
}
private Color finishColor = Color.FromArgb(183, 154, 205, 50);
/// <summary>
/// 步骤完成颜色(全局配置)
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "183, 154, 205, 50")]
[Description("步骤完成颜色(全局配置)")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color FinishColor
{
get { return this.finishColor; }
set
{
if (this.finishColor == value)
return;
this.finishColor = value;
this.Invalidate();
}
}
private StepItemCollection stepItemCollection;
/// <summary>
/// 步骤选项集合
/// </summary>
[DefaultValue(null)]
[Description("步骤选项集合")]
[DesignerSerializationVisibility(DesignerSerializationVisibility.Content)]
public StepItemCollection Items
{
get
{
if (this.stepItemCollection == null)
this.stepItemCollection = new StepItemCollection(this);
return this.stepItemCollection;
}
}
private int stepIndex = 0;
/// <summary>
/// 当前步骤的索引
/// </summary>
[DefaultValue(0)]
[Description("当前步骤的索引")]
public int StepIndex
{
get { return this.stepIndex; }
set
{
if (this.stepIndex == value)
return;
this.stepIndex = value;
this.Invalidate();
if (this.stepIndexChanged != null)
{
this.stepIndexChanged(this, new StepItemEventArgs() { Item = this.Items[this.stepIndex] });
}
}
}
#endregion
#region 步骤选项文本
private Font textFont = new Font("宋体", 11, FontStyle.Regular);
/// <summary>
/// 步骤选项文本字体
/// </summary>
[DefaultValue(typeof(Font), "11pt style=Regular")]
[Description("步骤选项文本字体")]
public Font TextFont
{
get { return this.textFont; }
set
{
if (this.textFont == value)
return;
this.textFont = value;
this.Invalidate();
}
}
private Color textColor = Color.FromArgb(154, 205, 50);
/// <summary>
/// 步骤选项文本颜色
/// </summary>
[DefaultValue(typeof(Color), "154, 205, 50")]
[Description("步骤选项文本颜色")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color TextColor
{
get { return this.textColor; }
set
{
if (this.textColor == value)
return;
this.textColor = value;
this.Invalidate();
}
}
#endregion
#region 提示信息
private bool tipShow = true;
/// <summary>
/// 是否显示提示信息
/// </summary>
[DefaultValue(true)]
[Description("是否显示提示信息")]
public bool TipShow
{
get { return this.tipShow; }
set
{
if (this.tipShow == value)
return;
this.tipShow = value;
}
}
/// <summary>
/// 提示信息标题背景颜色
/// </summary>
[DefaultValue(typeof(Color), "192, 206, 55")]
[Description("提示信息标题背景颜色")]
public Color TitleBackColor
{
get { return this.tooltip.TitleBackColor; }
set
{
if (this.tooltip.TitleBackColor == value)
return;
this.tooltip.TitleBackColor = value;
this.InitializeComponent();
}
}
/// <summary>
/// 提示信息标题颜色
/// </summary>
[DefaultValue(typeof(Color), "255, 255, 255")]
[Description("提示信息标题颜色")]
public Color TitleColor
{
get { return this.tooltip.TitleColor; }
set
{
if (this.tooltip.TitleColor == value)
return;
this.tooltip.TitleColor = value;
this.InitializeComponent();
}
}
/// <summary>
/// 提示信息文本字体
/// </summary>
[DefaultValue(typeof(Font), "宋体, 10pt")]
[Description("提示信息文本字体")]
public Font TipFont
{
get { return this.tooltip.Font; }
set
{
if (this.tooltip.Font == value)
return;
this.tooltip.Font = value;
}
}
/// <summary>
/// 提示信息文本颜色
/// </summary>
[Description("提示信息文本颜色")]
public Color TipColor
{
get { return this.tooltip.ForeColor; }
set
{
if (this.tooltip.ForeColor == value)
return;
this.tooltip.ForeColor = value;
}
}
#endregion
protected override Size DefaultSize
{
get
{
return new Size(300, 60);
}
}
protected override Padding DefaultPadding
{
get
{
return new Padding(20, 10, 20, 10);
}
}
/// <summary>
/// 提示信息
/// </summary>
private ToolTipExt tooltip;
/// <summary>
/// 提示信息状态
/// </summary>
private bool isshow = false;
#endregion
public StepProgressExt()
{
SetStyle(ControlStyles.UserPaint, true);
SetStyle(ControlStyles.AllPaintingInWmPaint, true);
SetStyle(ControlStyles.OptimizedDoubleBuffer, true);
SetStyle(ControlStyles.ResizeRedraw, true);
SetStyle(ControlStyles.SupportsTransparentBackColor, true);
InitializeComponent();
this.tooltip = new ToolTipExt();
this.tooltip.TitleShow = true;
this.tooltip.MinSize = new Size(70, 30);
this.tooltip.MaxSize = new Size(400, 0);
}
protected override void OnPaint(PaintEventArgs e)
{
base.OnPaint(e);
Graphics g = e.Graphics;
g.SmoothingMode = SmoothingMode.AntiAlias;
Rectangle rectf = new Rectangle(this.Padding.Left, this.Padding.Top, e.ClipRectangle.Width - this.Padding.Left - this.Padding.Right, e.ClipRectangle.Height - this.Padding.Top - this.Padding.Bottom);
#region 间隔线
for (int i = 1; i < this.Items.Count; i++)
{
#region 间隔线颜色
Color line_color = Color.Empty;
if (i < this.StepIndex - 1)
{
if (this.Items[i].FinishColor == Color.Empty)
line_color = this.FinishColor;
else
line_color = this.Items[i].FinishColor;
}
else if (i == this.StepIndex - 1)
{
if (this.Items[i].ProceedColor == Color.Empty)
line_color = this.ProceedColor;
else
line_color = this.Items[i].ProceedColor;
}
else
{
if (this.Items[i].NormalBackColor == Color.Empty)
line_color = this.NormalBackColor;
else
line_color = this.Items[i].NormalBackColor;
}
#endregion
PointF point_strat = new PointF(this.Items[i - 1].RectF.Right - this.StepLine + this.StepLine / 2, this.Items[i - 1].RectF.Y + this.Items[i].RectF.Height / 2);
PointF point_end = new PointF(this.Items[i].RectF.X + this.StepLine - this.StepLine / 2, this.Items[i].RectF.Y + this.Items[i].RectF.Height / 2);
if (this.Orientation == StepOrientation.VerticalLeft || this.Orientation == StepOrientation.VerticalRight)
{
point_strat = new PointF(this.Items[i - 1].RectF.X + this.Items[i].RectF.Width / 2, this.Items[i - 1].RectF.Bottom - this.StepLine + this.StepLine / 2);
point_end = new PointF(this.Items[i].RectF.X + this.Items[i].RectF.Width / 2, this.Items[i].RectF.Y + this.StepLine - this.StepLine / 2);
}
Pen line_pen = new Pen(line_color, this.StepLine);
g.DrawLine(line_pen, point_strat, point_end);
line_pen.Dispose();
}
#endregion
#region 圆
int text_space = 10;//文本离圆形距离
for (int i = 0; i < this.Items.Count; i++)
{
#region 圆形背景
#region 圆形背景颜色
Color circle_color = Color.Empty;
if (i < this.StepIndex - 1)
{
if (this.Items[i].FinishBackColor == Color.Empty)
circle_color = this.FinishBackColor;
else
circle_color = this.Items[i].FinishBackColor;
}
else
{
if (this.Items[i].NormalBackColor == Color.Empty)
circle_color = this.NormalBackColor;
else
circle_color = this.Items[i].NormalBackColor;
}
#endregion
SolidBrush circle_sb = new SolidBrush(circle_color);
g.FillEllipse(circle_sb, this.Items[i].RectF);
circle_sb.Dispose();
#endregion
#region 边框
#region 边框颜色
Color border_color = Color.Empty;
if (i < this.StepIndex - 1)
{
if (this.Items[i].FinishColor == Color.Empty)
border_color = this.FinishColor;
else
border_color = this.Items[i].FinishColor;
}
else if (i == this.StepIndex - 1)
{
if (this.Items[i].ProceedColor == Color.Empty)
border_color = this.ProceedColor;
else
border_color = this.Items[i].ProceedColor;
}
#endregion
if (i <= this.StepIndex - 1)
{
//圆形边框
Pen border_pen = new Pen(border_color, this.StepLine);
g.DrawEllipse(border_pen, TransformRectangleF(this.Items[i].RectF, this.StepLine));
border_pen.Dispose();
}
#endregion
#region 圆形圆心
if (i < this.StepIndex - 1)
{
float heart_w = this.Items[i].RectF.Width - this.StepLine * 2 - this.StepLine * 2;
float heart_h = this.Items[i].RectF.Height - this.StepLine * 2 - this.StepLine * 2;
RectangleF heart_rect = new RectangleF(this.Items[i].RectF.X + (this.Items[i].RectF.Width - heart_w) / 2, this.Items[i].RectF.Y + (this.Items[i].RectF.Height - heart_h) / 2, heart_w, heart_h);
SolidBrush heart_sb = new SolidBrush(this.Items[i].FinishColor == Color.Empty ? this.FinishColor : this.Items[i].FinishColor);
g.FillEllipse(heart_sb, heart_rect);
heart_sb.Dispose();
}
#endregion
#region 文本
StringFormat text_sf = new StringFormat();
text_sf.FormatFlags = StringFormatFlags.NoWrap;
text_sf.Alignment = StringAlignment.Center;
text_sf.Trimming = StringTrimming.None;
Size text_size = g.MeasureString(this.Items[i].Text, this.Items[i].TextFont, new SizeF(), text_sf).ToSize();
RectangleF text_rectf = new RectangleF(this.Items[i].RectF.X + (this.Items[i].RectF.Width - text_size.Width) / 2, this.Items[i].RectF.Bottom + text_space, text_size.Width, text_size.Height);
if (this.Orientation == StepOrientation.HorizontalBottom)
{
text_rectf.Y = this.Items[i].RectF.Y - text_space - text_size.Height;
}
else if (this.Orientation == StepOrientation.VerticalLeft)
{
text_rectf.X = this.Items[i].RectF.Right + text_space;
text_rectf.Y = this.Items[i].RectF.Y + (this.Items[i].RectF.Height - text_size.Height) / 2;
}
else if (this.Orientation == StepOrientation.VerticalRight)
{
text_rectf.X = this.Items[i].RectF.X - text_space - text_size.Width;
text_rectf.Y = this.Items[i].RectF.Y + (this.Items[i].RectF.Height - text_size.Height) / 2;
}
SolidBrush text_sb = new SolidBrush(this.Items[i].TextColor == Color.Empty ? this.TextColor : this.Items[i].TextColor);
g.DrawString(this.Items[i].Text, this.Items[i].TextFont, text_sb, text_rectf, text_sf);
text_sb.Dispose();
#endregion
}
#endregion
}
protected override void OnResize(EventArgs e)
{
base.OnResize(e);
this.InitializeSlideValueRectangleFs();
}
protected override void OnMouseLeave(EventArgs e)
{
base.OnMouseLeave(e);
this.isshow = false;
}
protected override void OnMouseMove(MouseEventArgs e)
{
base.OnMouseMove(e);
int index = this.GetSelectSlideIndex(this.PointToClient(Control.MousePosition));
if (index > -1)
{
if (!this.isshow)
{
ToolTipExt.ToolTipAnchor anchor = ToolTipExt.ToolTipAnchor.TopCenter;
if (this.Orientation == StepOrientation.HorizontalBottom)
{
anchor = ToolTipExt.ToolTipAnchor.BottomCenter;
}
else if (this.Orientation == StepOrientation.VerticalLeft)
{
anchor = ToolTipExt.ToolTipAnchor.LeftCenter;
}
else if (this.Orientation == StepOrientation.VerticalRight)
{
anchor = ToolTipExt.ToolTipAnchor.RightCenter;
}
Rectangle rect = new Rectangle((int)this.Items[index].RectF.X, (int)this.Items[index].RectF.Y, (int)this.Items[index].RectF.Width, (int)this.Items[index].RectF.Height);
this.tooltip.ToolTipTitle = this.Items[index].Text;
string str = this.Items[index].Description == String.Empty ? " " : this.Items[index].Description;
this.tooltip.Show(str, this, anchor, rect);
this.isshow = true;
}
if (this.Cursor != Cursors.Hand)
this.Cursor = Cursors.Hand;
}
else
{
if (this.isshow)
{
this.tooltip.Hide(this);
this.isshow = false;
}
if (this.Cursor != Cursors.Default)
this.Cursor = Cursors.Default;
}
}
#region
/// <summary>
/// 计算所有滑块rectf
/// </summary>
/// <param name="item"></param>
private void InitializeSlideValueRectangleFs()
{
for (int i = 0; i < this.Items.Count; i++)
{
this.InitializeSlideValueRectangleF(this.Items[i]);
}
}
/// <summary>
/// 计算指定滑块rectf
/// </summary>
/// <param name="item"></param>
private void InitializeSlideValueRectangleF(StepItem item)
{
Rectangle rect = new Rectangle(this.Padding.Left, this.Padding.Top, this.ClientRectangle.Width - this.Padding.Left - this.Padding.Right, this.ClientRectangle.Height - this.Padding.Top - this.Padding.Bottom);
int index = this.Items.IndexOf(item);
if (this.Orientation == StepOrientation.HorizontalTop || this.Orientation == StepOrientation.HorizontalBottom)
{
int slide_x = this.Padding.Left - this.StepRadius / 2 + index * this.StepSpace;
int slide_y = (this.Orientation == StepOrientation.HorizontalTop) ? this.Padding.Top + this.StepRadius / 2 : rect.Bottom - this.Padding.Bottom - this.StepRadius * 2;
item.RectF = new RectangleF(slide_x, slide_y, this.StepRadius * 2, this.StepRadius * 2);
}
else
{
int slide_x = (this.Orientation == StepOrientation.VerticalLeft) ? this.Padding.Top + this.StepRadius / 2 : rect.Right - this.Padding.Right - this.StepRadius;
int slide_y = this.Padding.Top - this.StepRadius / 2 + index * this.StepSpace;
item.RectF = new RectangleF(slide_x, slide_y, this.StepRadius * 2, this.StepRadius * 2);
}
}
/// <summary>
/// 获取选中滑块索引
/// </summary>
/// <param name="point">当前鼠标坐标</param>
/// <returns></returns>
private int GetSelectSlideIndex(Point point)
{
for (int i = 0; i < this.Items.Count; i++)
{
if (this.Items[i].RectF.Contains(point))
return i;
}
return -1;
}
/// <summary>
/// 根据画笔大小转换rectf
/// </summary>
/// <param name="rectf">要转换的rectf</param>
/// <param name="pen">画笔大小大小</param>
/// <returns></returns>
private static RectangleF TransformRectangleF(RectangleF rectf, int pen)
{
RectangleF result = new RectangleF();
result.Width = rectf.Width - (pen < 1 ? 0 : pen);
result.Height = rectf.Height - (pen < 1 ? 0 : pen);
result.X = rectf.X + (float)(pen / 2);
result.Y = rectf.Y + (float)(pen / 2);
return result;
}
#endregion
protected override void Dispose(bool disposing)
{
if (disposing && (components != null))
{
components.Dispose();
if (this.tooltip != null)
{
this.tooltip.Dispose();
}
}
base.Dispose(disposing);
}
/// <summary>
/// 步骤选项集合
/// </summary>
[Description("步骤选项集合")]
[Editor(typeof(CollectionEditorExt), typeof(UITypeEditor))]
public sealed class StepItemCollection : IList, ICollection, IEnumerable
{
private ArrayList stepItemList = new ArrayList();
private StepProgressExt owner;
public StepItemCollection(StepProgressExt owner)
{
this.owner = owner;
}
#region IEnumerable
public IEnumerator GetEnumerator()
{
StepItem[] listArray = new StepItem[this.stepItemList.Count];
for (int index = 0; index < listArray.Length; ++index)
listArray[index] = (StepItem)this.stepItemList[index];
return listArray.GetEnumerator();
}
#endregion
#region ICollection
public void CopyTo(Array array, int index)
{
for (int i = 0; i < this.Count; i++)
array.SetValue(this.stepItemList[i], i + index);
}
public int Count
{
get
{
return this.stepItemList.Count;
}
}
public bool IsSynchronized
{
get
{
return false;
}
}
public object SyncRoot
{
get
{
return (object)this;
}
}
#endregion
#region IList
public int Add(object value)
{
StepItem slideValue = (StepItem)value;
slideValue.owner = this.owner;
slideValue.self = slideValue;
this.stepItemList.Add(slideValue);
this.owner.InitializeSlideValueRectangleF(slideValue);
this.owner.Invalidate();
return this.Count - 1;
}
public void Clear()
{
this.stepItemList.Clear();
this.owner.Invalidate();
}
public bool Contains(object value)
{
return this.IndexOf(value) != -1;
}
public int IndexOf(object value)
{
return this.stepItemList.IndexOf(value);
}
public void Insert(int index, object value)
{
throw new NotImplementedException();
}
public bool IsFixedSize
{
get { return false; }
}
public bool IsReadOnly
{
get { return false; }
}
public void Remove(object value)
{
if (!(value is StepItem))
return;
this.stepItemList.Remove((StepItem)value);
this.owner.Invalidate();
}
public void RemoveAt(int index)
{
this.stepItemList.RemoveAt(index);
this.owner.Invalidate();
}
public StepItem this[int index]
{
get
{
return (StepItem)this.stepItemList[index];
}
set
{
this.stepItemList[index] = (StepItem)value;
this.owner.InitializeSlideValueRectangleF((StepItem)value);
this.owner.Invalidate();
}
}
object IList.this[int index]
{
get
{
return (object)this.stepItemList[index];
}
set
{
this.stepItemList[index] = (StepItem)value;
this.owner.InitializeSlideValueRectangleF((StepItem)value);
this.owner.Invalidate();
}
}
#endregion
}
/// <summary>
/// 步骤选项
/// </summary>
[Description("步骤选项")]
public class StepItem
{
[EditorBrowsable(EditorBrowsableState.Never)]
public StepItem()
{
}
public StepItem(StepProgressExt owner)
{
this.owner = owner;
}
/// <summary>
/// 控件主体
/// </summary>
public StepProgressExt owner;
/// <summary>
/// 当前步骤选项
/// </summary>
public StepItem self;
private RectangleF rectf = new RectangleF();
/// <summary>
/// 步骤rectf
/// </summary>
[Browsable(false)]
[Description("滑块rectf")]
public RectangleF RectF
{
get { return this.rectf; }
set
{
if (this.rectf == value)
return;
this.rectf = value;
}
}
private string text = "";
/// <summary>
/// 步骤文本
/// </summary>
[DefaultValue("")]
[Description("步骤文本")]
public string Text
{
get { return this.text; }
set
{
if (this.text == value)
return;
this.text = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
private Font textFont = new Font("宋体", 11, FontStyle.Regular);
/// <summary>
/// 步骤文本字体
/// </summary>
[DefaultValue(typeof(Font), "11pt style=Regular")]
[Description("步骤文本字体")]
public Font TextFont
{
get { return this.textFont; }
set
{
if (this.textFont == value)
return;
this.textFont = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
private Color textColor = Color.Empty;
/// <summary>
/// 步骤文本颜色
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "Empty")]
[Description("步骤文本颜色")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color TextColor
{
get { return this.textColor; }
set
{
if (this.textColor == value)
return;
this.textColor = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
private string description = "";
/// <summary>
/// 步骤文本描述
/// </summary>
[DefaultValue("")]
[Description("步骤文本描述")]
[Editor(typeof(MultilineStringEditor), typeof(System.Drawing.Design.UITypeEditor))]
public string Description
{
get { return this.description; }
set
{
if (this.description == value)
return;
this.description = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
private Color normalBackColor = Color.Empty;
/// <summary>
/// 步骤默认背景颜色
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "Empty")]
[Description("步骤默认背景颜色")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color NormalBackColor
{
get { return this.normalBackColor; }
set
{
if (this.normalBackColor == value)
return;
this.normalBackColor = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
private Color finishBackColor = Color.Empty;
/// <summary>
/// 步骤完成背景颜色
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "Empty")]
[Description("步骤完成背景颜色")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color FinishBackColor
{
get { return this.finishBackColor; }
set
{
if (this.finishBackColor == value)
return;
this.finishBackColor = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
private Color proceedColor = Color.Empty;
/// <summary>
/// 步骤开始颜色
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "Empty")]
[Description("步骤开始颜色")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color ProceedColor
{
get { return this.proceedColor; }
set
{
if (this.proceedColor == value)
return;
this.proceedColor = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
private Color finishColor = Color.Empty;
/// <summary>
/// 步骤完成颜色
/// </summary>
[Browsable(true)]
[DefaultValue(typeof(Color), "Empty")]
[Description("步骤完成颜色")]
[Editor(typeof(ColorEditorExt), typeof(System.Drawing.Design.UITypeEditor))]
public Color FinishColor
{
get { return this.finishColor; }
set
{
if (this.finishColor == value)
return;
this.finishColor = value;
if (this.owner != null)
{
this.owner.Invalidate();
}
}
}
}
/// <summary>
/// 步骤进度更改事件参数
/// </summary>
[Description("步骤进度更改事件参数")]
public class StepItemEventArgs : EventArgs
{
/// <summary>
/// 步骤选项
/// </summary>
[Description("步骤选项")]
public StepItem Item { get; set; }
}
/// <summary>
/// 控件步骤选项方向位置
/// </summary>
[Description("控件步骤选项方向位置")]
public enum StepOrientation
{
/// <summary>
///水平放置靠近上边
/// </summary>
HorizontalTop,
/// <summary>
/// 水平放置靠近下边
/// </summary>
HorizontalBottom,
/// <summary>
/// 垂直放置靠近左边
/// </summary>
VerticalLeft,
/// <summary>
/// 垂直放置靠近右边
/// </summary>
VerticalRight,
}
}源码下载：步骤进度控件.zip
来源：oschina
链接：https://my.oschina.net/u/4380330/blog/3413536
