curl和gopher协议（ssrf的利用）

由 元气小坏坏 提交于 2019-12-07 01:47:07

文章目录

一、基础知识的学习

(1) cURL

在这里插入图片描述
cURL是一个利用URL语法在命令行下工作的文件传输工具。它支持文件上传和下载，所以是综合传输工具。cURL还包含了用于程序开发的libcurl。

cURL支持的通信协议有：FTP、FTPS、HTTP、HTTPS、Gopher、SCP、Telnet、DICT、FILE、LDAP、LDAPS、IMAP、POP3、SMTP和RTSP。curl还支持SSL认证、HTTP POST、HTTP PUT、FTP。

curl protocol://address:port/url?args

(2) PHP的curl函数

菜鸟教程
PHP支持libcurl库与各种的服务器使用各种类型的协议进行连接和通讯。

几个相关函数
curl_init() 初始化一个cURL会话。

  • 初始化一个新的会话，返回一个cURL句柄，供curl_setopt(), curl_exec()和curl_close() 函数使用

curl_setopt() 设置一个cURL传输选项。

  • curl_setopt ( $ch , $option , $value )

curl_exec() 执行cURL会话。

curl_close() 关闭cURL会话。

【实列】

<?php
$ch = curl_init();
curl_setopt($ch, CURLOPT_URL, $_GET["url"]);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, 1);
curl_setopt($ch, CURLOPT_HEADER, 0);
$output = curl_exec($ch);
curl_close($ch);
?>

(3) gopher协议

gopher协议支持发出GET、POST请求：可以先拦截get请求包和post请求包，再构造成符合gopher协议的请求。gopher协议是ssrf利用中一个最强大的协议（俗称万能协议）。

可以攻击内网的 FTP、Telnet、Redis、Memcache，也可以进行 GET、POST 请求，还可以攻击内网未授权MySQL。

gopher://IP:port/_{TCP/IP数据流}

3.1 用gopher协议get传数据
//ssrf.php

<?php
$a = $_GET['test'];
echo $a ;
?>

【遇到了坑】

1.直接抓包，URL编码后用gopher协议发送

  • 在这里插入图片描述
    在这里插入图片描述

.
2. 最后是因为CRLF的问题，把url编码payload中的%0a改为%0d%0a

  • 在这里插入图片描述
curl gopher://127.0.0.1:80/_%47%45%54%20%2f%73%73%72%66%2e%70%68%70%3f%74%65%73%74%3d%61%61%61%20%48%54%54%50%2f%31%2e%31%0d%0a%48%6f%73%74%3a%20%31%32%37%2e%30%2e%30%2e%31%0d%0a%55%73%65%72%2d%41%67%65%6e%74%3a%20%4d%6f%7a%69%6c%6c%61%2f%35%2e%30%20%28%57%69%6e%64%6f%77%73%20%4e%54%20%31%30%2e%30%3b%20%57%69%6e%36%34%3b%20%78%36%34%3b%20%72%76%3a%37%30%2e%30%29%20%47%65%63%6b%6f%2f%32%30%31%30%30%31%30%31%20%46%69%72%65%66%6f%78%2f%37%30%2e%30%0d%0a%41%63%63%65%70%74%3a%20%74%65%78%74%2f%68%74%6d%6c%2c%61%70%70%6c%69%63%61%74%69%6f%6e%2f%78%68%74%6d%6c%2b%78%6d%6c%2c%61%70%70%6c%69%63%61%74%69%6f%6e%2f%78%6d%6c%3b%71%3d%30%2e%39%2c%2a%2f%2a%3b%71%3d%30%2e%38%0d%0a%41%63%63%65%70%74%2d%4c%61%6e%67%75%61%67%65%3a%20%7a%68%2d%43%4e%2c%7a%68%3b%71%3d%30%2e%38%2c%7a%68%2d%54%57%3b%71%3d%30%2e%37%2c%7a%68%2d%48%4b%3b%71%3d%30%2e%35%2c%65%6e%2d%55%53%3b%71%3d%30%2e%33%2c%65%6e%3b%71%3d%30%2e%32%0d%0a%43%6f%6e%6e%65%63%74%69%6f%6e%3a%20%63%6c%6f%73%65%0d%0a%55%70%67%72%61%64%65%2d%49%6e%73%65%63%75%72%65%2d%52%65%71%75%65%73%74%73%3a%20%31%0d%0a%43%61%63%68%65%2d%43%6f%6e%74%72%6f%6c%3a%20%6d%61%78%2d%61%67%65%3d%30%0d%0a%0d%0a
3.2 用gopher协议post传数据
//ssrf.php

<?php
$a = $_POST['test'];
echo $a ;
?>

curl gopher://47.101.14.211:80/_%50%4f%53%54%20%2f%73%73%72%66%2e%70%68%70%20%48%54%54%50%2f%31%2e%31%0d%0a%48%6f%73%74%3a%20%34%37%2e%31%30%31%2e%31%34%34%2e%31%39%37%0d%0a%55%73%65%72%2d%41%67%65%6e%74%3a%20%4d%6f%7a%69%6c%6c%61%2f%35%2e%30%20%28%57%69%6e%64%6f%77%73%20%4e%54%20%31%30%2e%30%3b%20%57%69%6e%36%34%3b%20%78%36%34%3b%20%72%76%3a%37%30%2e%30%29%20%47%65%63%6b%6f%2f%32%30%31%30%30%31%30%31%20%46%69%72%65%66%6f%78%2f%37%30%2e%30%0d%0a%41%63%63%65%70%74%3a%20%74%65%78%74%2f%68%74%6d%6c%2c%61%70%70%6c%69%63%61%74%69%6f%6e%2f%78%68%74%6d%6c%2b%78%6d%6c%2c%61%70%70%6c%69%63%61%74%69%6f%6e%2f%78%6d%6c%3b%71%3d%30%2e%39%2c%2a%2f%2a%3b%71%3d%30%2e%38%0d%0a%41%63%63%65%70%74%2d%4c%61%6e%67%75%61%67%65%3a%20%7a%68%2d%43%4e%2c%7a%68%3b%71%3d%30%2e%38%2c%7a%68%2d%54%57%3b%71%3d%30%2e%37%2c%7a%68%2d%48%4b%3b%71%3d%30%2e%35%2c%65%6e%2d%55%53%3b%71%3d%30%2e%33%2c%65%6e%3b%71%3d%30%2e%32%0d%0a%52%65%66%65%72%65%72%3a%20%68%74%74%70%3a%2f%2f%34%37%2e%31%30%31%2e%31%34%34%2e%31%39%37%2f%73%73%72%66%2e%70%68%70%0d%0a%43%6f%6e%74%65%6e%74%2d%54%79%70%65%3a%20%61%70%70%6c%69%63%61%74%69%6f%6e%2f%78%2d%77%77%77%2d%66%6f%72%6d%2d%75%72%6c%65%6e%63%6f%64%65%64%0d%0a%43%6f%6e%74%65%6e%74%2d%4c%65%6e%67%74%68%3a%20%39%0d%0a%4f%72%69%67%69%6e%3a%20%68%74%74%70%3a%2f%2f%34%37%2e%31%30%31%2e%31%34%34%2e%31%39%37%0d%0a%43%6f%6e%6e%65%63%74%69%6f%6e%3a%20%63%6c%6f%73%65%0d%0a%55%70%67%72%61%64%65%2d%49%6e%73%65%63%75%72%65%2d%52%65%71%75%65%73%74%73%3a%20%31%0d%0a%43%61%63%68%65%2d%43%6f%6e%74%72%6f%6c%3a%20%6d%61%78%2d%61%67%65%3d%30%0d%0a%0d%0a%74%65%73%74%3d%61%61%61%61

在这里插入图片描述

《post数据包》
POST /ssrf.php HTTP/1.1
Host: 47.101.14.211
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:70.0) Gecko/20100101 Firefox/70.0
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,/;q=0.8
Accept-Language: zh-CN,zh;q=0.8,zh-TW;q=0.7,zh-HK;q=0.5,en-US;q=0.3,en;q=0.2
Content-Type: application/x-www-form-urlencoded
Content-Length: 9
Connection: close
Upgrade-Insecure-Requests: 1
Cache-Control: max-age=0
.
test=aaaa

3.3 在ssrf中使用gopher协议

  • wireshark抓包，追踪数据流。转换为URL编码。 --> 使用gopher协议发送tcp/ip数据包

  • 想获取攻击的TCP数据包，可以使用socat进行端口转发

    curl gopher://127.0.0.1:80/_%47%45%54%20%2f%73%73%72%66%2e%70%68%70%3f%74%65%73%74%3d%61%61%61%20%48%54%54%50%2f%31%2e%31%0d%0a%48%6f%73%74%3a%20%31%32%37%2e%30%2e%30%2e%31%0d%0a%55%73%65%72%2d%41%67%65%6e%74%3a%20%4d%6f%7a%69%6c%6c%61%2f%35%2e%30%20%28%57%69%6e%64%6f%77%73%20%4e%54%20%31%30%2e%30%3b%20%57%69%6e%36%34%3b%20%78%36%34%3b%20%72%76%3a%37%30%2e%30%29%20%47%65%63%6b%6f%2f%32%30%31%30%30%31%30%31%20%46%69%72%65%66%6f%78%2f%37%30%2e%30%0d%0a%41%63%63%65%70%74%3a%20%74%65%78%74%2f%68%74%6d%6c%2c%61%70%70%6c%69%63%61%74%69%6f%6e%2f%78%68%74%6d%6c%2b%78%6d%6c%2c%61%70%70%6c%69%63%61%74%69%6f%6e%2f%78%6d%6c%3b%71%3d%30%2e%39%2c%2a%2f%2a%3b%71%3d%30%2e%38%0d%0a%41%63%63%65%70%74%2d%4c%61%6e%67%75%61%67%65%3a%20%7a%68%2d%43%4e%2c%7a%68%3b%71%3d%30%2e%38%2c%7a%68%2d%54%57%3b%71%3d%30%2e%37%2c%7a%68%2d%48%4b%3b%71%3d%30%2e%35%2c%65%6e%2d%55%53%3b%71%3d%30%2e%33%2c%65%6e%3b%71%3d%30%2e%32%0d%0a%43%6f%6e%6e%65%63%74%69%6f%6e%3a%20%63%6c%6f%73%65%0d%0a%55%70%67%72%61%64%65%2d%49%6e%73%65%63%75%72%65%2d%52%65%71%75%65%73%74%73%3a%20%31%0d%0a%43%61%63%68%65%2d%43%6f%6e%74%72%6f%6c%3a%20%6d%61%78%2d%61%67%65%3d%30%0d%0a%0d%0a

socat -v tcp-listen:4444,fork tcp-connect:localhost:80
> 2019/11/05 17:13:17.180806  length=516 from=0 to=515
POST /ssrf.php HTTP/1.1\r
Host: 47.101.1.17\r
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:70.0) Gecko/20100101 Firefox/70.0\r
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/*;q=0.8\r
Accept-Language: zh-CN,zh;q=0.8,zh-TW;q=0.7,zh-HK;q=0.5,en-US;q=0.3,en;q=0.2\r
Referer: http://47.101.144.197/ssrf.php\r
Content-Type: application/x-www-form-urlencoded\r
Content-Length: 9\r
Origin: http://47.101.144.197\r
Connection: close\r
Upgrade-Insecure-Requests: 1\r
Cache-Control: max-age=0\r
\r
test=aaaa> 2019/11/05 17:13:17.188171  length=2 from=516 to=517
\r
< 2019/11/05 17:13:17.188281  length=171 from=0 to=170
HTTP/1.1 200 OK\r
Date: Tue, 05 Nov 2019 09:13:17 GMT\r
Server: Apache/2.4.18 (Ubuntu)\r
Content-Length: 5\r
Connection: close\r
Content-Type: text/html; charset=UTF-8\r
\r
aaaa

(4) file协议和dict协议

ssrf中利用 file 协议可以读取任意内容
在这里插入图片描述

dict协议可以进行内网端口探测
在这里插入图片描述

ssrf攻击redis
